Комбиновање АИРТАЦ АЦ БЦ серије Ф Р Л

MODEL

AC1500

AC2000

BC2000

BC3000

BC4000

Air filter

AF1500

AF2000

BF2000

BF3000

BF4000

Pressure regulator

AR1500

AR2000

BF2000

BF3000

BF4000

Air lubricator

AL1500

AL2000

BL2000

BL3000

BL4000

Port size

G1/8

G1/4

G1/4

G3/8

G1/2

Working medium

AIR

Adjust pressure range

0.05-0.085Mpa(7-121psi)

Maximum adjustable pressure

0.95Mpa(135psi)

Proof pressure

1.5 Mpa (213 PSI）

temperature range

5-60 ℃

Filter precision

40μm

capacity of oil bowl

15CC

60CC

capacity of water bowl

25CC

90CC

weight（kg)

0.26

0.4

Material :

 Main body :Aluminum alloy

Oil bowl:PC

AC1500-AC2000（without bowl guard);BC2000-BC4000(with PA66 bowl guard)

Ordering code

AC

2000

A

MODEL

port size

Drain type

AC:A series lubricator(small)

1500:G1/8

Blank:Semi-auto drain

BC:B series lubricator(big)

2000:G1/4

D:Manual drain

3000:G3/8

A:Auto drain

4000:G1/2

AC:no Auto drain
